Liquid pressure and temperature sensor (10bar / 140 deg C)
Product Details
Combined sensor for pressure and temperature measurement of oil. Stainless steel sealing ring included
More information
M10x1.0 thread.
- pin2: Pressure signal out (0.5V = 0bar, 4.5V = 10bar)
- pin3: +5V sensor supply
- pin4: Sensor GND
- pin5: Temperature signal out (0.5V = -40 deg C, 4.5V = 140 deg C)
The pressure output is wired to an AIN (0-5V) input.
The temperature output is wired to an AIN (TEMP) input which has built-in +5V pullup.
